Cross Point RF Deactivator
KSh 148,500(KSh 172,260 Incl VAT)
- Cross Point RF Deactivator – Short Key Features
- 8.2 MHz Operation: Supports standard RF soft labels
- High-Speed Deactivation: Up to 120 labels per minute
- Detect-Before-Deactivate: Ensures label presence before deactivation
- POS Interlock: Can be controlled by cash register input
- Visual & Audible Feedback: LED indicators and buzzer confirm status
- Compact Design: Low-profile 240 × 240 mm footprint
- Flexible Mounting: Suitable for countertop or under-counter installation
- CrossCONNECT Ready: Optional remote diagnostics and performance monitoring
- Energy Efficient: Low power consumption with stable DC output
- Retail-Grade Durability: Built for high-volume environments
SKU: RF DeactivatorCategory: Point of Sale
Tags:POS
The Cross Point RF Deactivator is a high-speed, compact 8.2 MHz EAS label deactivator designed for use at retail checkout counters. It ensures seamless label detection and deactivation, supporting fast-paced POS operations while providing advanced visual and audible feedback to operators. Engineered for high throughput and integration readiness, it meets the rigorous demands of modern retail security infrastructure.
RF & Detection Specifications
- Frequency Range: 8.2 MHz ± 0.5 MHz
- Label Compatibility: RF soft labels (paper/adhesive/disposable)
- Detection Height: Up to 30 cm for 4 × 4 cm labels
- Deactivation Rate: Up to 120 labels per minute
- Detection & Deactivation Logic: Detect-before-deactivate algorithm ensures label presence before processing
- Technology: Single-loop and dual-loop antenna support for scanner integration or stand-alone operation
Physical & Mechanical Specifications
- Dimensions: Approx. 240 mm × 240 mm active surface area
- Build Material: Industrial-grade ABS plastic housing
- Mounting Options:
- Countertop with optional sleek cover
- Under-counter flush integration
- Design: Low-profile form factor to maximize counter space
Electrical Specifications
- Input Voltage: 220 VAC
- Power Output: 18 V DC, 1 A (18 W)
- Consumption: Low power draw with efficient internal processing
- POS Integration: Deactivation function controllable via POS system interlock
User Interface & Feedback
- Visual Indicator: LED panel confirms label detection and successful deactivation
- Audio Feedback: Configurable buzzer signals success/failure per label
- Adjustable Settings: Buzzer volume, detection sensitivity, and LED indicators customizable
Operational Features
- Smart Count Logging: Tracks quantity and timestamps of deactivations (optional feature)
- CrossCONNECT Compatibility:
- Enables remote diagnostics, reporting, and firmware updates
- Supports integration with store-level monitoring systems
- Security Monitoring: Real-time operational status and device alerts available (connected variant only)
Installation & Compatibility
- Supported Systems: Fully compatible with Cross Point RF antenna systems (e.g., MODUS RF30)
- Integration: Works with most POS scanners using scanner loop or antenna field
- Connectivity Options: Standard power and optional POS data port for interlock
Environmental Conditions
- Operating Temperature: 0 °C to 45 °C
- Humidity: 0% to 90% non-condensing
- Durability: Designed for continuous operation in retail environments with high transaction volumes
Benefits
- Fast and reliable deactivation for a smoother checkout process
- Visual and audible confirmation eliminates uncertainty for staff
- Reduces false alarms at store exits when paired with RF pedestals
- Supports analytics and reporting with optional connected capabilities
- Easy to install and compatible with standard retail counter setups
Meta Description
Cross Point RF Deactivator is a high-performance 8.2 MHz deactivation system for retail use. It features a 240×240 mm surface, up to 120 labels/min rate, POS interlock, LED and buzzer feedback, and remote management via CrossCONNECT—ideal for modern checkout environments. DatasheetRelated Products
