Cross Point Ostra & Shell D40

The Cross Point Ostra & Shell D40 (OSTRA D40 and SHELL D40) are premium 8.2 MHz RF hard tags designed for retail electronic article surveillance (EAS) systems. These tags provide effective theft deterrence, durable construction, and compatibility with most RF systems. They feature secure locking mechanisms and optimized detection profiles for both mono and dual-antenna setups. While similar in form factor and frequency, they differ slightly in internal design and shell construction.

---

Common Specifications for Both Tags

• Tag Type: RF (Radio Frequency) EAS Hard Tag
• Operating Frequency: 8.2 MHz
• Technology: Acousto-Magnetic (for AM variants), but D40 is strictly RF
• Detection Method: Passive resonance circuit detectable by compatible RF systems
• Application Areas: Fashion, sportswear, accessories, general retail
• Tag Shape: Circular shell design
• Color Options: Glossy black, glossy white, or custom (on request)
• Pin Compatibility: 20 mm steel or plastic pin
• Lock Type: Standard mechanical clutch or optional SuperLock / HyperLock
• Deactivation: Requires manual detacher; not deactivatable like soft labels
• Durability: Impact-resistant ABS shell, resistant to tampering and corrosion
• Temperature Tolerance: Operational up to 50°C, storage up to 70°C
• Moisture Resistance: Yes, suitable for standard retail indoor humidity

---

Physical Specifications

Feature	OSTRA D40	SHELL D40
Diameter	40 mm	40 mm
Thickness	17 mm	17 mm
Weight	Approx. 15 g	Approx. 15 g
Shell Material	Industrial-grade ABS	Reinforced ABS shell
Color Finish	Glossy black/white	Matte black/white or smooth gloss

---

Cross Point Ostra & Shell D40 Detection Range

Antenna System Type	OSTRA D40 Range	SHELL D40 Range
RF Mono	Up to 1.2 m	Up to 1.0 m
RF Dual	Up to 2.05 m	Up to 1.85 m

Range may vary based on system calibration, antenna positioning, and store layout.

---

Security & Performance

• Code Lock Feature (OSTRA only): Proprietary locking mechanism prevents tampering
• Tamper Resistance: Shells designed to resist forced pin extraction
• Resonator Quality: High-sensitivity components ensure reliable detection
• Magnetic Detacher Compatibility: Works with most standard and SuperLock detachers
• Deactivation/Removal: Manual detacher only; cannot be turned off electronically

---

Use Cases & Advantages

• Ideal for apparel, accessories, sports gear, and boxed items
• Low false-alarm rates due to tuned resonator coils
• Consistent tag performance across antenna models
• Aesthetic and unobtrusive on merchandise
• Long lifecycle with reusability for several years

---

Packaging & Logistics

• Standard Packing Unit: 1,000 tags per carton
• Inner Packaging: 100 tags per sleeve or tray
• Carton Weight: Approx. 15–16 kg per box
• Labeling: Includes frequency marking, batch ID, and serial (optional)

---

Summary

The OSTRA D40 is optimized for higher-end retail environments requiring strong tamper resistance and extended detection range, while the SHELL D40 offers a rugged yet cost-efficient option with slightly reduced performance but full compatibility with standard RF systems. Both deliver high detection reliability, easy reuse, and strong visual deterrence in a compact design.

---
