Ruijie RG-EG310GH-E, Reyee 10-Port Cloud Managed Office Router
KSh 24,500(KSh 28,420 Incl VAT)
- 10 × Gigabit ports – 1 WAN, 6 LAN, 3 LAN/WAN (up to 4 WAN links)
- High performance – up to 1.5 Gbps throughput (1 Gbps with full services)
- Supports up to 300 concurrent users – ideal for growing businesses
- Advanced VPN support – IPsec, L2TP, PPTP, OpenVPN (64 tunnels max)
- Cloud-managed – via Ruijie Cloud & Reyee App (zero-touch setup)
- Traffic control & QoS – application-based bandwidth and policy management
- Strong security – ACLs, firewall, anti-DoS, malicious attack defense
- Captive portal – supports vouchers, SMS, QR code, and password login
- Manages up to 500 APs & 128 switches in AC mode
- Fanless rackmount design – quiet and space-saving with surge protection
SKU: RG-EG310GH-ECategory: Networking Infrastructure
Here are the detailed specifications for the RG‑EG310GH‑E, Ruijie’s high-performance 10‑port, cloud‑managed office router:
This model is ideal for SMBs requiring solid throughput, flexible WAN, strong VPN/security, and scalable cloud-managed deployments in a professional rack format. Datasheet
🔌 Physical Interfaces
- 10 × 10/100/1000 Mbps RJ‑45 ports:
- 1 fixed WAN
- 6 fixed LAN
- 3 switchable LAN/WAN (up to 4 WAN links total)
🧠 Hardware & Performance
- CPU: Dual-core 1.35 GHz
- Memory: 512 MB DDR, Storage: 256 MB SPI flash
- Throughput:
- Up to 1.5 Gbps (NAT + flow audit)
- ~1.0 Gbps with full services (DPI, authentication, flow control)
- Concurrent Clients: Recommended for ~300; designed to support up to 350 users
- Power Consumption: ❗ Typically ≤ 15 W (some sources list ≤ 25 W)
🌐 Networking & VPN
- Multi‑WAN: Failover/load balancing over up to 4 WAN ports
- VPN Support: IPsec, L2TP, PPTP, OpenVPN
- IPsec tunnels: up to 64
- Throughput: ~230 Mbps IPsec, ~640 Mbps L2TP, ~100 Mbps OpenVPN
🔐 Security & Traffic Control
- Firewall & ACLs, anti-DoS/flood, port-scan/malicious attack mitigation
- Advanced Filtering: Application block/list, web filters, PBR, smart QoS
- Captive Portal: WiFiDog, voucher, QR code, SMS, username/password login
☁️ Cloud & Management Features
- Ruijie Cloud + Reyee App: Zero-touch provisioning, remote monitoring/upgrades
- Network Management Capacity:
- Router mode: up to 150 AP/NBS + 128 switches
- AC mode: up to 500 AP/NBS + 128 switches
🛠️ Physical & Environmental
- Form Factor: 1U rack-mounted, fanless for low noise
- Dimensions/Weight: 440 × 200 × 43.6 mm; ~2.4 kg
- Operating Conditions: 0–40 °C; 10–90% humidity; IP20; 4 kV surge protection
- Certifications & Warranty: CE, RoHS; 3-year warranty
📦 Package Contents
Comes with rack brackets, power cord, user manual, warranty card✅ Summary Table
| Feature | Details |
|---|---|
| Ports | 1 WAN, 6 LAN, 3 switchable LAN/WAN (10 × RJ-45 total) |
| CPU / RAM / Storage | Dual-core 1.35 GHz; 512 MB RAM, 256 MB Flash |
| Throughput | 1.5 Gbps NAT; 1 Gbps full services |
| VPN Tunnels | IPsec / L2TP / PPTP / OpenVPN (up to 64) |
| VPN Performance | ~230 Mbps (IPsec), 640 Mbps (L2TP), 100 Mbps (OpenVPN) |
| Clients Supported | Recommended ~300 |
| Multi-WAN | Up to 4 with load balancing & failover |
| Power | ≤ 15 W (some sources say ≤ 25 W) |
| Weight / Size | 2.4 kg; 440 × 200 × 43.6 mm (1U) |
| Cooling & Build | Fanless, rack-mount, IP20 |
| Warranty | 3 years |
This model is ideal for SMBs requiring solid throughput, flexible WAN, strong VPN/security, and scalable cloud-managed deployments in a professional rack format. Datasheet
