Ubiquiti UniFi USW Pro 48 Switch (PoE & Non-PoE)

Discover the UniFi USW-Pro-48 and USW-Pro-48-PoE switches — enterprise-grade Layer 3 network switches with 48 GbE ports, 10GbE SFP+ uplinks, advanced routing, PoE++ support, and UniFi touchscreen interface for high-performance deployments.

---

🛠️ USW‑Pro‑48 (Non‑PoE)

• Ports:
  • 48 × 1 GbE RJ45
  • 4 × 1/10 GbE SFP+ uplinks
• Performance:
  • Switching capacity: 176 Gbps
  • Non‑blocking throughput: 88 Gbps
  • Forwarding rate: ~131 Mpps
• Layer 2 & 3 Features:
  • Supports up to 1,000 VLANs, LACP, STP/RSTP, QoS, IGMP snooping, jumbo frames, 802.1X, ACLs
  • Layer 3: Static & inter‑VLAN routing, DHCP server/relay, DHCP snooping, port isolation, ACLs
• Hardware & Design:
  • 1.3″ touchscreen display with Etherlighting™
  • 1U rack‑mountable chassis (442 × 285 × 44 mm)
  • Weight: ~4.0 kg (4.1 kg with brackets)
  • Passively cooled, fanless design—nearly silent
• Power:
  • Internal AC/DC PSU (100–240 V) 60 W typical draw (≈205 BTU/hr)
  • USP-RPS DC backup support
• Environment & Compliance:
  • Operating temperature: –5 °C to 40 °C; humidity: 10–90% non-condensing
  • Certifications: CE, FCC, IC; NDAA compliant

---

⚡ USW‑Pro‑48‑PoE (PoE Model)

Includes all of the non‑PoE specs, plus:

• PoE Ports & Budget:
  • 48 × 1 GbE RJ45 (40 ports PoE+ @ 32 W max; 8 ports PoE++ @ 60 W max)
  • 4 × 10 GbE SFP+ uplinks
  • Total PoE budget: 600 W
• Power Supply:
  • Internal AC/DC PSU rated 660 W; 60 W idle consumption; up to 660 W under full PoE load
  • DC backup via USP-RPS supported
• Cooling:
  • Active and intelligent fan cooling—remains quiet even with PoE load
• Dimensions & Weight:
  • 442 × 399.6 × 43.7 mm; weight ~6.2 kg (6.3 kg with brackets)

---

✅ Summary Comparison

Feature	USW‑Pro‑48 (Non‑PoE)	USW‑Pro‑48‑PoE
RJ45 Ports	48× 1 GbE	48× 1 GbE (PoE+: 40 / PoE++: 8)
SFP+ Uplinks	4× 10 GbE	4× 10 GbE
Switching Capacity	176 Gbps	176 Gbps
Non-blocking Throughput	88 Gbps	88 Gbps
Forwarding Rate	~131 Mpps	~131 Mpps
Touchscreen	✔	✔
Cooling	Passive, fanless	Active fans (quiet operation)
Power Supply	Internal 60 W	Internal 660 W
PoE Budget	—	600 W total
Power Backup Support	✅ via USP‑RPS	✅ via USP‑RPS
Size & Weight	442 × 285 × 44 mm; ~4 kg	442 × 400 × 44 mm; ~6.2 kg
Environment & Certs	Same	Same

---

Note: Both models require the UniFi Network Controller (v5.10.5 / v8.0.24+) and are NDAA-compliant, making them suitable for enterprise deployments.

---

Datasheet (USW‑Pro‑48)

Datasheet (USW‑Pro‑48-PoE)
