MikroTik RBD4011iGS+5HacQ2HnD-IN Wireless Router

The MikroTik RBD4011iGS+5HacQ2HnD-IN Wireless Router is a high-performance, dual-band Wi-Fi router designed for power users, professionals, and businesses that require fast wireless and wired connectivity. Equipped with a powerful quad-core CPU, ten Gigabit Ethernet ports, and a 10G SFP+ port, it also includes PoE capabilities, dual-band wireless with 4x4 MIMO on 5 GHz, and IPsec hardware acceleration—all in a sleek, compact metal enclosure.

---

🧠 Core Hardware Specifications

• Product Model: RBD4011iGS+5HacQ2HnD-IN
• CPU: Annapurna Labs AL21400, quad-core ARM Cortex-A15, 1.4 GHz
• Architecture: ARM 32-bit
• RAM: 1 GB DDR3
• Storage: 512 MB NAND
• RouterOS License: Level 5
• Operating System: RouterOS v7
• Cooling: Passive (fanless)
• MTBF: Over 200,000 hours at 25°C

---

📶 Wireless Capabilities

• 5 GHz Band:
  • Wi-Fi Standard: 802.11a/n/ac (Wi-Fi 5)
  • Configuration: 4x4 MU-MIMO
  • Max Data Rate: 1733 Mbps
  • Chipset: QCA9984
  • Antenna Gain: ~3 dBi
  • Integrated 4x external antennas with 360° coverage
• 2.4 GHz Band:
  • Wi-Fi Standard: 802.11b/g/n (Wi-Fi 4)
  • Configuration: 2x2 MIMO
  • Max Data Rate: 300 Mbps
  • Chipset: R11e-2HnD
  • Antenna Gain: ~3 dBi

---

🌐 Networking Interfaces

• Ethernet:
  • 10 × 10/100/1000 Mbps Gigabit Ethernet ports
• SFP+:
  • 1 × 10 Gbps SFP+ port
• MiniPCIe Slot:
  • Occupied by 2.4 GHz wireless module
• Serial Console:
  • RJ45

---

⚡ Powering Options

• Power Inputs:
  • DC jack (12–57 V)
  • Passive PoE-in on port 1 (18–57 V)
• Power Output:
  • Passive PoE-out on port 10 (up to 600 mA at 18–30 V or 420 mA at 30–57 V)
• Power Consumption:
  • Without attachments: ~23 W
  • With PoE-out and wireless: ~44 W
• Power Adapter Included: Yes (24 V 1.5 A)

---

🔐 Security & Features

• Hardware IPsec Acceleration: Yes
• Advanced Routing: Static, OSPF, BGP, MPLS
• Firewall and NAT: Full support
• Wireless Modes: AP, station, bridge, repeater
• VPN Protocols: IPsec, OpenVPN, PPTP, L2TP, SSTP
• Monitoring Tools: Netwatch, SNMP, Traffic Flow
• Virtualization: Not supported (no container or VM support)
• Management: CLI, Winbox, WebFig

---

🛠️ Physical and Environmental

• Dimensions: 228 x 120 x 30 mm
• Weight: ~800 g
• Mounting Options: Desktop or wall-mountable
• Enclosure Material: Rugged metal
• Operating Temperature Range: -40°C to +45°C
• Humidity Tolerance: Up to 90% non-condensing

📝 Meta Description

  MikroTik RBD4011iGS+5HacQ2HnD-IN Wireless Router is a powerful dual-band Wi-Fi router with 10 Gigabit Ethernet ports, 10G SFP+, PoE-in/out, 1 GB RAM, and IPsec acceleration. Ideal for high-performance home or office networks. Datasheet
