Ruijie RG-EG105GW(T) Wi-Fi 5 1267Mbps Wireless All-in-One Business Router

The RG‑EG105GW(T) is a sleek, desktop (or wall-mountable) all‑in‑one enterprise-class wireless router ideal for SOHO environments like cafes, stores, or small offices. It boasts 5 gigabit Ethernet ports—1 fixed WAN, 1 fixed LAN, and 3 LAN/WAN switchable—supporting up to 4 WAN links for robust load balancing. The dual-band Wi‑Fi 5 radios deliver a combined AC1300 (1267 Mbps) throughput, leveraging MU‑MIMO 2×2 on both 2.4 GHz and 5 GHz bands

Designed for up to 150 total concurrent users (≈110 wireless, ≈80 recommended on Wi‑Fi) and around 600 Mbps recommended data throughput, it’s powered by a dual-core 880 MHz CPU, 256 MB RAM, and 32 MB flash. Versatile WAN configuration and Reyee Mesh support (one-touch setup) extend reach with optional AP or mesh nodes.

Security and networking features include IPSec/OpenVPN/L2TP/PPTP VPN, multiple VLANs, captive portals, smart flow control, and cloud-based management through Ruijie Cloud and the Reyee app. With a compact form factor (120 × 120 × 28 mm), USB 2.0 port, 12 V/1.5 A power supply, and a 3-year warranty, it offers a powerful, easy-to-manage solution for modern small-business networking

Here are the detailed specifications for the RG‑EG105GW(T) desktop all‑in‑one enterprise‑class wireless router:

---

📡 Wireless Features

• Dual‑band Wi‑Fi 5 (802.11a/b/g/n/ac Wave 1/2)
  • 2.4 GHz: up to 400 Mbps (2×2 MIMO, 3 dBi gain)
  • 5 GHz: up to 867 Mbps (2×2 MIMO, 4 dBi gain)
  • Combined AC1300 peak rate: 1,267 Mbps
• Spatial streams: 2×2 on both bands
• Transmit power & sensitivity:
  • ≤ 26 dBm (2.4 GHz), ≤ 25 dBm (5 GHz) (adjustable)
  • Typical Wi‑Fi receive sensitivity down to –91 dBm

---

🔌 Ethernet & WAN/LAN Ports

• 5 × 10/100/1000 Mbps ports:
  • 1 fixed WAN, 1 fixed LAN, 3 switchable WAN/LAN (supports up to 4 WAN links)
• USB support: 1 × USB 2.0 port

---

⚙️ Hardware & Performance

• CPU: Dual‑core 880 MHz
• Memory: 256 MB DDRIII RAM, 32 MB flash storage
• Throughput: ~600 Mbps recommended routing performance

---

👥 User Capacity

• Wireless clients: Max 110; recommended 80
• Total clients (LAN + Wi‑Fi): Up to 150

---

🔐 Networking & Security

• WAN capabilities: Multi-WAN support (failover & load balancing) up to 4 WAN links
• VPN support: IPSec, OpenVPN, L2TP, PPTP
• Security & QoS:
  • Firewall, ACLs, attack detection/prevention
  • Smart flow control, app/web filtering
  • Captive portal with vouchers, QR, SMS, etc.

---

☁️ Cloud & Mesh Management

• Cloud-managed via Ruijie Cloud and Reyee App
• One-touch Reyee Mesh support
• Management scope: As router, controls up to 32 APs/NBS & 128 switches
• Extras: DDNS, firmware updates, remote monitoring, APP library updates

---

🛠️ Physical & Power

• Dimensions: 120 × 120 × 28 mm; weight ~0.25 kg
• Mounting: Desktop (vertical/horizontal) or wall-mountable
• Power supply: 12 V / 1.5 A DC adapter (≤ 15 W consumption)
• Environment: Operating temp 0–40 °C, humidity 5–95 % non-condensing
• Certifications: CE, RoHS; fanless design; MTBF > 400,000 h

---

✅ Summary

The RG‑EG105GW(T) is a robust Wi‑Fi 5 AC1300 all‑in‑one wireless router with multi‑WAN, dual‑band concurrent support, enterprise‑grade VPN and security, cloud mesh management, and high connectivity capacity in a compact, fanless desktop/wall format. Ideal for SOHO, retail, hospitality, and small to mid‑size business deployments. Datasheet
