RG-NBS5200-48GT4XS-UP, 48-port Gigabit Layer 3 PoE Switch, 4 SFP+ Uplink

KSh 156,000(KSh 180,960 Incl VAT)

48 × Gigabit PoE+ ports (IEEE 802.3af/at/bt)
4 × 10G SFP+ uplink ports
740W PoE budget, supports PoE++
Layer 3 features: Static Routing, RIP, OSPF
Cloud management via Ruijie Cloud & Mobile App
Advanced security: 802.1X, ACLs, DHCP snooping
Switching capacity: 176 Gbps, Forwarding rate: 132 Mpps
Fan cooling with adaptive speed, Surge protection: 6 kV
Web, CLI, and SNMP management
5-year warranty

SKU: RG-NBS5200-48GT4XS-UPCategory: Networking Infrastructure

The Ruijie Reyee RG-NBS5200-48GT4XS-UP is a high-performance Layer 3 managed PoE switch designed for enterprise, campus, hospitality, and industrial networks. It offers robust switching capabilities, advanced Layer 3 features, and cloud-based management.

🔧 Key Specifications

Ports:
- 48 × 10/100/1000Base-T PoE+ ports
- 4 × SFP+ (10G) uplink ports
PoE Capabilities:
- Supports IEEE 802.3af/at/bt standards
- 8 × PoE++ (802.3bt) ports
- Maximum PoE budget: 740W
Performance:
- Switching capacity: 176 Gbps
- Forwarding rate: 132 Mpps
- MAC address table: 16,000 entries
- Packet buffer: 16 Mbit
- VLAN support: up to 4094 VLANs
Layer 2 Features:
- Jumbo frames up to 9216 bytes
- Flow control
- STP (IEEE 802.1d), RSTP (IEEE 802.1w)
- Port Fast, BPDU Guard, Errdisable Recovery
- Link aggregation: up to 16 groups with 8 members each
- Storm control for unknown unicast, multicast, and broadcast traffic
- VLAN types: port-based, MAC-based, IP-based, voice VLAN
- LLDP/LLDP-MED, RLDP, cable testing
- IGMP Snooping v1/v2/v3
Layer 3 Features:
- Static routing
- OSPF and RIP support
- Access Control Lists (ACLs): IP standard, MAC-based extended, IP-based extended
- SNMP v1/v2c/v3
- 802.1X authentication
- IPv6 support
- DHCP server and client
Management:
- Web-based GUI (HTTP/HTTPS)
- Cloud management via Ruijie Cloud platform
- Self-Organizing Network (SON) for zero-touch provisioning
- Camera recognition, loop prevention, PoE usage alarms
Hardware:
- Flash memory: 256MB
- Power supply: Single fixed, 100–240V AC, 10A
- Power consumption: ≤ 815.6W
- Cooling: 3 fans with adaptive speed control
- Airflow: Left/Right-to-Rear
- Acoustic noise: < 65dB
- Operating temperature: 0°C to 50°C
- Storage temperature: -40°C to 70°C
- Operating humidity: 10% to 90% RH
- Storage humidity: 5% to 95% RH
- Port surge protection: 6 kV
- MTBF: > 200,000 hours
- Dimensions (W × D × H): 440 mm × 357.6 mm × 43.6 mm
- Weight (with package): 7.23 kg
Certifications:
- CE, RoHS
Warranty:
- 5 years
