MikroTik RBmAP2nD mAP (micro Access Point)

The MikroTik RBmAP2nD mAP (micro Access Point) is a small and versatile wireless device designed for mobile networking, travel setups, or as a compact SOHO access point. Despite its size, it runs a full RouterOS license (Level 4) and includes dual powering options, passive PoE support, and repeater or AP functionality. It's highly useful for on-the-go professionals, IT field engineers, or portable test labs.

---

🧠 Core Hardware Specifications

• Model: RBmAP2nD
• Product Name: mAP
• CPU: QCA9531, 650 MHz
• Architecture: MIPS 32-bit
• RAM: 64 MB
• Storage: 16 MB Flash
• Operating System: RouterOS
• RouterOS License: Level 4

---

📶 Wireless Specifications

• Wireless Standard: 802.11b/g/n (Wi-Fi 4)
• Frequency Band: 2.4 GHz
• Chains: 1×1 SISO
• Max Data Rate: 150 Mbps
• Antenna Gain: ~1.5 dBi (internal)
• Wireless Modes: AP, station, WDS, repeater, bridge

---

🌐 Networking Interfaces

• Ethernet Ports:
  • 2 × 10/100 Mbps Fast Ethernet ports
  • First port supports passive PoE input
  • Second port can output passive PoE (up to 500 mA)

---

⚡ Powering Options

• Power Inputs:
  • Passive PoE-in: 11–57 V (on Ether1)
  • MicroUSB (5 V)
• PoE-Out:
  • Passive PoE out on Ether2 (up to 500 mA at input voltage)
• Power Consumption:
  • Up to 5 W with PoE-out
• Adapter Included: Yes (5 V 1 A USB adapter)

---

🔐 Software & Features

• RouterOS Level 4: Supports wireless AP and routing features
• Networking: NAT, firewall, routing (static/dynamic)
• VPN Support: IPsec, PPTP, L2TP, OpenVPN (basic)
• Management: Winbox, WebFig, SSH, SNMP, CLI
• Wireless Tools: Snoop, Scan, Frequency usage, Repeater
• Other Tools: Bandwidth test, Torch, Ping, Packet sniffer

---

📦 Physical & Environmental

• Dimensions: 68 × 68 × 19 mm
• Weight: ~65 g
• Mounting: Desktop, wall-mount or suction cup (included)
• Cooling: Passive
• Enclosure: Plastic
• Operating Temp Range: -10°C to +70°C
• LEDs: Power, Wireless activity

📝 Meta Description

  MikroTik RBmAP2nD mAP (micro Access Point) is a compact wireless access point with 2 Ethernet ports, 2.4 GHz Wi-Fi at 150 Mbps, PoE-in/out support, microUSB power, and RouterOS Level 4 license—ideal for portable Wi-Fi, mobile setups, or compact network deployments. Datasheet
