Ubiquiti UniFi Standard 48 Switch (PoE & Non-PoE)

The UniFi USW-48 and USW-48-PoE are silent, enterprise-grade Layer 2 switches with 48 GbE ports, 4 SFP uplinks, advanced VLAN and QoS support, touchscreen Here are the comprehensive specifications for the UniFi USW‑48 (“Standard”) and USW‑Pro‑48 (non‑PoE & PoE) models from Ubiquiti's official sources:

---

🔹 USW‑48 (Standard, Non‑PoE)

• Ports: 48 × 1 GbE RJ45 + 4 × 1 GbE SFP uplinks
• Performance: 104 Gbps switching capacity, 52 Gbps non‑blocking throughput, 77 Mpps forwarding rate
• Layer 2 Features: 1,000 VLANs, LACP, STP/RSTP, IGMP snooping (advanced), jumbo frames, 802.1X, ACLs, DHCP snooping, storm control, voice VLAN, LLDP-MED, port mirroring
• Hardware: 1U rack, 1.3″ touchscreen, steel chassis, fanless/passive cooling, 442 × 285 × 44 mm, 3.9 kg
• Power: Internal 60 W AC/DC PSU, typical draw 40 W (~136 BTU/hr)
• Environment & Compliance: –15 °C to 40 °C, 10–90% non-condensing; CE, FCC, IC; NDAA compliant

---

🔹 USW‑48‑PoE (Standard PoE Model)

• Ports: 48 × 1 GbE (32 PoE+ ports) + 4 × 1 GbE SFP
• PoE Budget: 195 W total; up to 32 W per port
• Performance & Specs: Same capacity/throughput/forwarding as non‑PoE model
• Dimensions/Weight: 4.5–4.6 kg; same chassis size
• Power: 240 W internal PSU; draw 45 W idle, 240 W max (excluding PoE)
• Cooling & Compliance: Passive cooling; same environmental specs and certifications

---

🔹 USW‑Pro‑48 (Pro, Non‑PoE)

• Ports: 48 × 1 GbE + 4 × 10 GbE SFP+ uplinks
• Performance: 176 Gbps switching, 88 Gbps non‑blocking throughput, 131 Mpps forwarding rate
• Layer 3 Support: Static/inter‑VLAN routing, DHCP server/relay, 1,000 VLANs, 16,000 MAC, 4,000 ARP, 1,000 IPv4 routes
• Hardware: 1U rack, touchscreen, steel chassis, passive cooling, same dimensions, weight ~4 kg
• Power: Internal 60 W PSU, typical draw 60 W (~205 BTU/hr); USP-RPS DC backup supported
• Compliance: –5 °C to 40 °C, 10‑90% RH; CE, FCC, IC; NDAA compliant

---

🔹 USW‑Pro‑48‑PoE (Pro PoE Model)

• Ports: 48 × 1 GbE RJ‑45 (40 PoE+ @ 32 W, 8 PoE++ @ 64 W) + 4 × 10 GbE SFP+
• PoE Budget: 600 W total PoE
• Performance: Matches Pro non‑PoE (176 Gbps / 88 Gbps / 131 Mpps)
• Hardware: Active but quiet fans, DC backup, touchscreen, 442 × 400 × 44 mm; 6.2 kg (6.3 kg with brackets)
• Power: Internal 660 W PSU; idle ~60 W excluding PoE, up to 660 W with PoE
• Compliance: Same operating ranges; CE, FCC, IC; NDAA compliant

---

🔍 Summary Table

Model	RJ45 Ports	Uplinks	Switching / Throughput / Forwarding	PoE Budget
USW‑48	48 × 1 GbE	4 × 1 GbE SFP	104 Gbps / 52 Gbps / 77 Mpps	—
USW‑48‑PoE	48 × 1 GbE (32 PoE+)	4 × 1 GbE SFP	Same as USW‑48	195 W PoE
USW‑Pro‑48	48 × 1 GbE	4 × 10 GbE SFP+	176 Gbps / 88 Gbps / 131 Mpps	—
USW‑Pro‑48‑PoE	48 × 1 GbE (40 PoE+, 8 PoE++)	4 × 10 GbE SFP+	Same as Pro‑48	600 W PoE

---

🧠 Real-World Insights

• Non-PoE models are truly fanless and nearly silent—great for noise-sensitive environments
• Pro models with PoE include fans but are reported to be “near-silent” in typical deployments .
• Consider the port speed, PoE needs, and routing requirements—Pro models add Layer 3 capabilities and higher bandwidth.

---

Datasheet (USW‑48)

Datasheet (USW‑48-PoE)
