Tycon TP-VRHP-4856 Voltage Converter

The Tycon TP-VRHP-4856 Voltage Converter is a high-performance, industrial-grade isolated DC-to-DC voltage converter designed to supply 56VDC at up to 1.25A (70W) from a wide input voltage range of 36–72VDC. Built for mission-critical infrastructure, it features robust protections, high isolation, and DIN rail mount compatibility. This converter is ideal for powering high-voltage PoE devices, wireless base stations, and telecom equipment in remote and demanding environments.

---

⚡ Electrical Specifications

• Input Voltage Range: 36VDC to 72VDC
• Output Voltage: 56VDC (regulated)
• Output Current: 1.25A (continuous)
• Maximum Output Power: 70 Watts
• Conversion Efficiency: Greater than 85%
• Load Regulation: ±5%
• Line Regulation: ±1%
• Ripple & Noise:
  • Ripple: 2%
  • Noise (peak): 5%
• Isolation:
  • Input to Output: ≥1500VDC
  • Isolation Resistance: ≥100MΩ
• Start-Up Time: <1 second typical
• Protections:
  • Short circuit protection (auto-recovery)
  • Overvoltage protection
  • Overload protection
  • Low-voltage disconnect feature

---

🏗️ Mechanical and Physical Specifications

• Enclosure Type: Rugged metal housing
• Mounting: DIN rail mount included
• Dimensions: 133mm × 76mm × 38mm (5.24" × 3.00" × 1.50")
• Weight: Approximately 298g (10.5 oz)
• Connectors: Terminal block supports up to 12 AWG wiring
• Cooling Method: Passive convection (fanless operation)

---

🌡️ Environmental Ratings

• Operating Temperature: –30°C to +65°C (–22°F to +149°F)
• Storage Temperature: –40°C to +85°C
• Humidity: 0% to 90% non-condensing
• Ingress Protection: Sealed enclosure; suitable for industrial environments

---

🛡️ Safety and Compliance

• Electrical Isolation: 1500VDC isolation ensures safety for sensitive systems
• Protection Features:
  • Auto-recovery from short circuits
  • Overvoltage cutoff
  • Overcurrent limiting
  • Low-voltage disconnect prevents deep battery discharge
• Certifications: RoHS compliant
• Warranty: 3 years (manufacturer warranty)

---

🧰 Primary Applications

• Wireless access points and high-voltage PoE equipment
• Remote telecom and base station power systems
• Industrial controls and monitoring systems
• Battery-powered or off-grid system integrations
• Surveillance and security devices requiring 56VDC

---
