Tycon TP-DCDC-4824G - DC to DC Converter

KSh 14,000(KSh 16,240 Incl VAT)

Converts 36–72VDC input to regulated 24VDC output
Integrated passive PoE injector (pins 4,5 V+ and 7,8 V−)
Delivers up to 24W continuous, 30W peak power
High efficiency >90% for low heat generation
Built-in protections: surge, ESD, short-circuit, reverse polarity
Wide operating temperature: -40°C to +70°C
Compact, lightweight, and easy to install
Ideal for IP cameras, wireless radios, and industrial devices

SKU: TP-DCDC-4824GCategory: Power solutions

The Tycon TP-DCDC-4824G is a high-performance, industrial-grade DC-to-DC converter specifically engineered for powering 24V passive PoE (Power over Ethernet) devices from a 48VDC power source. This model is part of Tycon Power Systems’ extensive portfolio designed to support remote power applications in harsh environments such as telecom, surveillance, wireless backhaul, and industrial automation. Compact yet rugged, the TP-DCDC-4824G offers regulated output, integrated passive PoE injection, and exceptional power efficiency, making it ideal for mission-critical applications requiring reliability and voltage conversion precision.

Electrical Specifications

Input Voltage Range: 36VDC to 72VDC
Input Current: 0.65A @ 48VDC input (typical)
Output Voltage: 24VDC ± 5% (regulated)
Output Power: 24W continuous, 30W max peak
Efficiency: > 90% at 48V input
Output Current: 1.0A @ 24VDC
Output Type: Passive PoE (non-802.3af/at compliant)
PoE Pinout: Pins 4,5 (+), 7,8 (-)
Ripple and Noise: < 100mV peak-to-peak
Load Regulation: ±1%
Line Regulation: ±1%

Mechanical Specifications

Dimensions: 85mm x 58mm x 24mm (3.35" x 2.3" x 0.95")
Weight: 150g (0.33 lbs)
Case Material: High-impact ABS plastic
Mounting: Integral mounting tabs for easy surface or DIN rail mounting

Environmental Ratings

Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Storage Temperature: -40°C to +85°C (-40°F to +185°F)
Humidity: 5% to 95% non-condensing
Ingress Protection: Indoor use only (IP20)
Cooling: Passive (no moving parts)

Compliance & Protections

EMI Compliance: FCC Class B
ESD Protection: ±15kV (Air), ±8kV (Contact)
Surge Protection: IEC 61000-4-5 compliant
Input Reverse Polarity Protection: Yes
Output Overcurrent Protection: Yes, automatic recovery
Overvoltage Protection: Yes
Short Circuit Protection: Yes

Applications

Wireless Access Points (non-802.3af/at)
Remote IP Cameras and Surveillance
Industrial Sensors and Automation
Powering low-voltage PoE bridges or routers
Wireless CPE and AP radios

Features Summary

Converts 48VDC to regulated 24VDC with passive PoE output
High-efficiency design with low power dissipation
Integrated surge, ESD, and short-circuit protection
Compact and lightweight for space-constrained deployments
Designed for industrial and remote environments
Plug-and-play installation with built-in PoE injector

Meta Description: Discover the Tycon TP-DCDC-4824G, a 48V to 24V passive PoE converter delivering 24W regulated output, ideal for industrial and telecom applications. Rugged, efficient, and protected. Datasheet
