Teltonika RUTX50 Industrial 5G Router

The Teltonika RUTX50 Industrial 5G Router is a powerful industrial 5G router designed for mission-critical applications that demand ultra-fast, low-latency, and highly reliable mobile connectivity. Built with carrier aggregation support and backward compatibility with 4G and 3G networks, it ensures uninterrupted performance across multiple environments including enterprise, industrial automation, transportation, and public safety.

---

Mobile Connectivity

• Mobile Network Support:
  • 5G NR: Sub-6 GHz, NSA/SA, 3GPP Release 15
  • 4G LTE: Cat 20, up to 2.0 Gbps DL / 200 Mbps UL
  • 3G: UMTS/HSPA+ fallback
• 5G DL/UL Speeds: Up to 3.3 Gbps / 900 Mbps (theoretical max)
• Carrier Aggregation: 4×4 MIMO, supports advanced CA profiles for improved performance
• SIM Slots:
  • 2× External mini-SIM slots (3FF)
  • SIM switching logic based on signal strength, data usage, roaming, or link loss

---

Wi-Fi & Ethernet

• Wi-Fi:
  • IEEE 802.11a/b/g/n/ac (Wi-Fi 5), Wave 2
  • Dual-band 2.4 GHz and 5 GHz
  • MU-MIMO, up to 867 Mbps
  • 2× RP-SMA connectors for external antennas
  • Fast roaming (802.11r/k/v) support
• Ethernet:
  • 5× Gigabit Ethernet ports (1 WAN + 4 LAN)
  • Auto MDI/MDIX support
  • VLAN support, port-based isolation
  • Load balancing and WAN failover

---

GNSS (Global Navigation)

• Integrated GNSS receiver
  • Supports GPS, GLONASS, Galileo, BeiDou
  • SMA connector for external GNSS antenna
  • Grounding screw for GNSS surge protection

---

Hardware Specifications

• CPU: Quad-core ARM Cortex-A7, 717 MHz
• RAM: 256 MB DDR3
• Flash Memory: 256 MB NAND
• USB: 1× USB 2.0 Type-A (data & power, up to 0.5 A)
• I/O Ports:
  • 1× Digital Input
  • 1× Open-collector Output
  • Reset button
• Antenna Ports:
  • 4× SMA for 5G/4G LTE
  • 2× RP-SMA for Wi-Fi
  • 1× SMA for GNSS

---

Power Supply & Consumption

• Power Input Range: 9 – 50 VDC
• Passive PoE (on ETH1): 9 – 50 VDC
• Typical Power Consumption: 4 W (idle)
• Max Power Consumption: Up to 18 W

---

Software & Management

• Operating System: RutOS (based on OpenWRT)
• Remote Management: Compatible with Teltonika RMS (Remote Management System)
• Web UI: Intuitive interface via HTTP/HTTPS
• CLI: SSH, Telnet
• API Support: JSON-RPC, MQTT, SNMP v1/v2/v3
• Monitoring:
  • Real-time mobile signal status
  • Reboot via ping/Wget trigger
  • Log export and diagnostics

---

Networking & Security Features

• VPN Support:
  • OpenVPN (client/server)
  • IPsec (IKEv1/v2)
  • WireGuard
  • L2TP, PPTP, SSTP, DMVPN, GRE
• Firewall & Routing:
  • Stateful firewall, NAT, port forwarding
  • Static/dynamic routing (BGP, OSPF, RIP, EIGRP, VRRP)
  • VLAN tagging (IEEE 802.1Q)
  • Traffic shaping and bandwidth control
• Other Security Features:
  • MAC/IP filtering
  • Access control lists (ACLs)
  • Brute-force protection
  • DoS protection
  • Captive portal

---

Mechanical & Environmental

• Housing: Rugged aluminum casing
• Mounting Options:
  • DIN-rail mount
  • Wall mount
• Dimensions: 132 × 44.2 × 100 mm
• Weight: Approx. 520 g
• Operating Temperature: –40 °C to +75 °C
• Humidity: 10% – 90% non-condensing
• Ingress Protection: IP30

---

Certifications & Standards

• CE, UKCA, FCC
• RoHS & REACH compliant
• EN 62368-1, EN 301 489, EN 301 511, EN 301 908, EN 303 413

---

Included Accessories

• 4× LTE antennas
• 2× Wi-Fi antennas
• 1× GNSS antenna
• Power supply unit
• Ethernet cable
• Quick start guide
• SIM adapters

---

Meta Description

The Teltonika RUTX50 Industrial 5G Router is an ultra-fast 5G industrial router offering dual SIM, 5× Gigabit Ethernet, dual-band Wi-Fi 5, GNSS, and advanced VPN and security features. Built for demanding industrial and enterprise applications, it delivers peak performance with carrier aggregation, passive PoE, and remote management via RutOS and RMS. Datasheet
