Teltonika RUTX11 LTE-A Cat 6 Gigabit Cellular Router

The Teltonika RUTX11 LTE-A Cat 6 Gigabit Cellular Router is an industrial LTE‑Advanced Cat 6 router delivering robust connectivity for IoT/M2M deployments. With carrier aggregation providing up to 300 Mbps downlink speeds, it combines wired, wireless, GNSS, and multiple I/O options in a rugged aluminum enclosure

---

Cellular & SIM

• 4G LTE‑Cat 6: Up to 300 Mbps DL / 50 Mbps UL
• 3G fallback: DC‑HSPA+ (up to 42 Mbps DL)
• Dual external SIM slots: Auto‑failover based on signal, data/SMS limit, roaming, idle timeout
• Carrier Aggregation: Supports intra-band and inter-band 2CA
• Modem compliance: 3GPP Release 12 compliant
• Antenna Connectors: 2× SMA (LTE Main & Aux)

---

Networking & Wi‑Fi

• Ethernet: 4× Gigabit ports (1 WAN configurable as LAN + 3 LAN), auto MDIX, VLAN support (up to 128 tags)
• Wi‑Fi: Dual-band Wi‑Fi 5 (802.11ac Wave‑2 + b/g/n); AP/Station modes; MU‑MIMO; up to 867 Mbps; supports captive portal and internal RADIUS
• Bluetooth LE: For sensor connectivity

---

GNSS

• Supported Systems: GPS, GLONASS, Galileo, BeiDou, QZSS
• Functions: Geofencing, NMEA, tracking, time sync

---

I/O & Ports

• Digital I/O: 1 digital input + 1 open-collector output (30 V / 300 mA) via 4‑pin connector
• Serial: Not included (unlike RUT955)
• USB Host: 1× USB‑A for storage/devices
• SIM Reset & Factory Reset buttons

---

Hardware & Power

• CPU: Quad-core ARM Cortex‑A7 @ 717 MHz
• Memory: 256 MB DDR3 RAM + 256 MB SPI Flash storage
• Power Input: 9–50 V DC via 4‑pin terminal; supports passive PoE
• Power Consumption: Approx. 11–18 W under load

---

Physical & Environment

• Housing: Rugged aluminum + plastic, IP30 rated; includes grounding screw; DIN‑rail/wall-mount options
• Dimensions: 115 × 44.2 × 95.1 mm (without antennas)
• Weight: ~456 g
• Operating Temp: –40 °C to +75 °C; Humidity: 10–90% non-condensing

---

Software, Security & Management

• Operating System: RutOS based on OpenWRT
• Routing: Static & dynamic (BGP, OSPF, RIP v1/v2, EIGRP, VRRP)
• VPN Support: OpenVPN, IPsec, PPTP, L2TP, GRE, SSTP, WireGuard, DMVPN, Stunnel, ZeroTier
• Firewall & Security: Stateful, DoS protection, MAC/IP filtering, VLAN separation
• Cloud Management: Teltonika RMS, SNMP v1/2/3, TR-069, SSH, CLI, SMS, JSON-RPC
• IoT Protocols: MQTT, Modbus, Samba, WOL, DLNA, NTP
• Wi‑Fi Security: WPA2-Enterprise, Captive portal, RADIUS support

---

Compliance & Certification

• Standards: CE/RED, FCC, IC, RoHS, WEEE
• EMC: EN 55032/35, ETSI EN 301 489, ISO 7637
• Rail Compliance: EN 45545-2 certified for use on passenger trains

---

In the Box

• RUTX11 unit with power supply (region-specific), 2 LTE antennas, 2 Wi‑Fi antennas, 1 GNSS antenna, 1 BT antenna, Ethernet cable, SIM tool & adapters, quick start guide

---

Meta Description

Teltonika RUTX11 LTE-A Cat 6 Gigabit Cellular Router is a rugged LTE‑Cat 6 industrial router with dual SIM failover, carrier aggregation (300 Mbps), 4× Gbps Ethernet ports, dual-band Wi-Fi 5, Bluetooth LE, GNSS, USB and digital I/O, running RutOS with VPN support and remote management—built for demanding IoT and transport applications. Datasheet
