Ruijie RG-WALL 1600-Z3200-S, Next-Gen Z Series Firewall

KSh 82,000(KSh 95,120 Incl VAT)

Up to 10 Gbps firewall throughput with 1.8 Mpps packet forwarding
Advanced NGFW features: IPS, antivirus, app control, URL filtering (via license)
Supports 500,000 concurrent sessions and 50,000 new sessions/sec
Robust VPN performance: 2.6 Gbps IPsec, 384 Mbps SSL VPN
Cloud-managed via Ruijie Cloud with remote diagnostics and policy push
Rich connectivity: 8 x GE ports, 1 x SFP (1G), 1 x SFP+ (10G), 1 x console, 2 x USB
Smart traffic learning, port scanning detection, policy simulation tools
1U rack-mount design, <25W power consumption, and low-noise operation
Ideal for medium to large enterprises and branch environments
3-year warranty and full CE/LVD/EMC certifications

SKU: RG-WALL 1600-Z3200-SCategory: Security solutions

Here are the detailed specifications for the Ruijie RG‑WALL 1600‑Z3200‑S, a high‑performance, cloud‑managed next‑generation firewall in a 1U rack form factor:

🧩 Interfaces & Hardware

Ports:
- 8 × 10/100/1000 Mbps Ethernet (auto-negotiation)
- 1 × 1 Gbps SFP optical
- 1 × 10 Gbps SFP+ (auto-negotiation to 1G)
Management & Expansion:
- 1 × RJ‑45 Management (shared with LAN 0/0)
- 1 × Console (RS‑232 CLI)
- 2 × USB 2.0 ports
- Optional 1 TB SATA HDD bay

⚙️ Performance & Capacity

Throughput (hardware limits):
- Firewall (1518-byte UDP): 10 Gbps, 1.8 Mpps
- NGFW (with IPS, APP control): up to 1.6 Gbps (with licenses)
- IPS performance: up to 2 Gbps with performance license
VPN Performance:
- IPsec: 1.3–2.6 Gbps, up to 1,000 tunnels
- SSL VPN: up to 384 Mbps; supports ~500 users
- App control (HTTP): ~3 Gbps
Session Handling:
- Concurrent sessions: 500,000
- New sessions/sec: 50,000
- Policy entries: 3,000

🛡️ Security & Software Capabilities

Full NGFW: Firewall, IPS, antivirus, application control, URL filtering (via subscription licenses)
Intelligent policy tools: Port-scan + Traffic Learning wizard, policy simulation before deployment
Defense mechanisms: Anti‑DoS/DDoS, ARP defense, virus templates, threat intel integration
Cloud-based features: Central management, remote monitoring, one-click diagnostics, auto policy deployment via Ruijie Cloud

🛠️ Physical, Power & Environmental Specs

1U rack design: 440 × 200 × 43.6 mm; 2.9 kg
Power: Internal AC PSU (100–240 V, max < 25 W)
Env. Conditions: 0–45 °C, 5–95% RH non-condensing, up to 5 km altitude
Noise: 43.7 dB
Certifications: EMC, LVD; 3‑year warranty

💼 Ideal Use Cases

An enterprise-grade, cloud-managed NGFW geared for mid-to-large organizations—such as schools, hotels, hospitals, and branches—requiring high throughput, extensive VPN capacity, deep packet inspection, and intelligent policy management in a compact rack unit. Datasheet
