Posiflex EK-2110 Self-Service Kiosk

The Posiflex EK-2110 is a compact all-in-one self-service kiosk terminal built for versatility and performance in modern retail, hospitality, and ticketing environments. It features a P-CAP touchscreen in portrait orientation, powered by Android 10 with Google Mobile Services (GMS), and comes with integrated camera, printer, Wi-Fi, and 2D barcode scanner. Designed for smooth interaction and minimal footprint, the EK-2110 delivers an efficient and elegant customer engagement solution.

---

Detailed Specifications

Display & Design

• Display Type: P-CAP (Projected Capacitive) Touch Panel
• Display Orientation: Portrait
• Glass Type: Without Anti-Glare (AG) glass
• Status Indicator: SI-100 LED indicator for operational status
• Color: Sleek black finish
• Design Type: Integrated pedestal design for compact installation
• Camera: Built-in front camera for user verification or image capture

Performance & Hardware

• Processor: ARM-based SoC optimized for Android kiosk applications
• Operating System: Android 10 with Google Mobile Services (GMS) certification
• Memory (RAM): 4GB DDR DRAM
• Storage: 32GB eMMC internal storage
• Power Supply: UK power cord, 100–240V AC input
• Cooling System: Fanless silent operation

Connectivity & Communication

• Wireless Connectivity: Integrated Wi-Fi module (WF770EK)
• 4G Connectivity: Not included
• Ethernet: RJ45 LAN port (optional)
• USB Ports: Multiple for peripheral expansion
• Audio: Built-in speaker support
• Interface: Android-compatible input/output configuration

Integrated Peripherals

• Printer:
  • Model: PP7600EK00000
  • Type: Thermal printer (512 dots per line)
  • Language: English, West Europe character set
• Barcode Scanner:
  • Model: CD3601EK
  • Type: 2D barcode scanner (reads all major 1D/2D codes)
• Camera: Integrated for ID capture or video verification
• Status Indicator: SI-100 LED module for system status notification
• Wi-Fi: WF770EK wireless module
• Fingerprint Reader: Not included
• Payment Device Bracket: Not included
• Pedestal: Standard Posiflex pedestal stand

Compatibility & Software

• OS Support: Android 10 (with GMS)
• App Support: Compatible with Google Play-enabled kiosk apps
• Use Cases:
  • Retail point-of-sale (POS)
  • Queue management
  • Check-in/out kiosk
  • Self-ordering or ticketing station

Physical & Environmental

• Construction: Industrial-grade materials for continuous public use
• Cooling: Fanless thermal design
• Operating Temperature: 0°C to 40°C
• Humidity: 20% – 80% (non-condensing)
• Color: Black finish

---

Key Features

• Portrait P-CAP touchscreen for intuitive interaction
• Android 10 with GMS for reliable app compatibility
• Integrated printer and 2D barcode scanner for complete kiosk functionality
• Built-in camera and Wi-Fi module for enhanced versatility
• Compact pedestal design ideal for retail and hospitality spaces
• LED status indicator for real-time system feedback
• Fanless and durable construction for 24/7 operation

---

Meta Description

Posiflex EK-2110 Self-Service Kiosk – 10-inch portrait P-CAP touchscreen Android terminal with camera, printer, 2D barcode scanner, Wi-Fi, and pedestal. Powered by Android 10 with GMS, 4GB RAM, 32GB eMMC. Ideal for retail and hospitality self-service applications. Datasheet
