MSI MAG CORELIQUID A15 360 360mm AIO CPU Cooler ARGB

Datasheet

Short Description

The MSI MAG CORELIQUID A15 360 is a flagship 360mm all-in-one liquid CPU cooler, designed to deliver ultimate cooling performance for the most demanding systems . Featuring 3 pre-installed CycloBlade 9 ARGB fans, a large 360mm radiator, and an adjustable offset kit, it provides exceptional thermal dissipation and stunning ARGB GEN2 lighting for high-end gaming and workstation builds .

Key Sections

Ultimate 360mm AIO with Adjustable Offset Kit

The CORELIQUID A15 360 features a large 360mm aluminum radiator and a high-performance pump with a full-copper cold plate, offering superior heat dissipation for the most demanding processors . Its adjustable offset kit allows for precise alignment of the cold plate with the CPU, ensuring optimal heat transfer and significantly improving cooling performance . This is ideal for overclocking and high-TDP processors.

Pre-Installed CycloBlade 9 ARGB Fans

The cooler comes with 3 × 120mm ARGB PWM fans pre-installed for a streamlined assembly experience . Featuring MSI's CycloBlade 9 hybrid blade design, these fans deliver a powerful airflow of 64.89 CFM at speeds between 500 and 2050 RPM . The ARGB GEN2 lighting effects can be customized through MSI Center, allowing for a personalized lighting experience .

Broad Compatibility with UNI Bracket

The CORELIQUID A15 360 features a pre-installed UNI Bracket that supports both Intel and AMD sockets, reducing assembly time . It is compatible with the latest Intel LGA 1700 / 1851 and AMD AM4 / AM5 platforms . The high-quality EPDM tubing is durable and prevents coolant evaporation, ensuring a long-lasting, sealed system .

Core Features

• 360mm aluminum radiator and high-performance pump for maximum cooling .

• Adjustable offset kit for precise CPU alignment and improved cooling performance .

• 3 × 120mm CycloBlade 9 ARGB PWM fans with airflow up to 64.89 CFM .

• ARGB GEN2 lighting with MSI Mystic Light compatibility .

• Pre-installed UNI Bracket supports Intel LGA 1700/1851 and AMD AM4/AM5 .

Performance & Utility Features

• The CycloBlade 9 fan design provides powerful airflow and high static pressure .

• A full-plane copper cold plate with micro-channels ensures efficient heat absorption .

• The adjustable offset kit ensures optimal CPU coverage .

• EPDM braided tubing prevents coolant evaporation .

Design, Build & Sustainability

• The military-inspired design features sharp, angular lines and a brushed aluminum accent .

• Hidden daisy-chain fan cabling simplifies installation and improves aesthetics .

• EPDM tubing ensures long-term durability and leak protection .

Technical Specifications Summary

• Model / Part Number: MSI MAG CORELIQUID A15 360

• Cooler Type: 360mm All-in-One Liquid CPU Cooler

• Radiator Size: 394 x 119.6 x 27.2 mm

• Fans: 3 × 120mm CycloBlade 9 ARGB PWM Fans (Pre-installed)

• Fan Speed: 500 – 2050 RPM

• Airflow: 64.89 CFM

• Socket Support: Intel LGA 1700 / 1851, AMD AM4 / AM5

• Materials: Aluminum Radiator, Copper Cold Plate

• Lighting: ARGB GEN2 / MSI Mystic Light Compatible

• Special Features: Adjustable Offset Kit, UNI Bracket, EPDM Tubing, Hidden Daisy-Chain Cabling
