Lenovo ThinkPad X9-14 Intel Core Ultra 7 258V 21QA0014UE

Datasheet

Short Description

The Lenovo ThinkPad X9-14 Aura Edition Laptop (21QA0014UE) is a premium, AI-powered Copilot+ PC designed to redefine executive mobility and productivity . Featuring a stunning 14-inch 2.8K OLED touch display with a 120Hz variable refresh rate, the Intel Core Ultra 7 258V processor with integrated Intel AI Boost (up to 47 TOPS), 32GB of ultra-fast LPDDR5X-8533 memory, and a 1TB PCIe Gen4 NVMe SSD, this revolutionary ThinkPad delivers exceptional performance, enterprise-grade security, and cutting-edge AI capabilities in a sleek, lightweight aluminum chassis .

---

Key Sections

Revolutionary Design & Build Quality

The ThinkPad X9-14 marks a bold new direction for the ThinkPad brand, featuring a revolutionary design that blends aesthetics with functionality . Crafted with an ultrathin aluminum frame, the Thunder Grey chassis exudes premium sophistication while delivering the legendary durability you expect from a ThinkPad . Weighing just 1.21 kg and measuring a mere 6.7mm at its slimmest point, this ultraportable is designed for the most demanding mobile professionals . Despite its slim profile, it meets MIL-STD-810H military-grade durability standards against shock, vibration, and extreme temperatures .

Stunning 14-Inch 2.8K OLED Touch Display

The ThinkPad X9-14 features a breathtaking 14-inch 2.8K (2880 x 1800) OLED touch display with 500 nits peak brightness and 100% DCI-P3 color gamut coverage . The display incorporates Anti-Reflection/Anti-Smudge technology, reducing reflections and keeping the screen clean during use . The 30-120Hz variable refresh rate (VRR) dynamically adapts to content, saving battery life while delivering ultra-smooth visuals . The panel supports Dolby Vision and DisplayHDR True Black 600 for an immersive entertainment experience .

Flagship Intel Core Ultra Processing with AI Acceleration

Under the hood, the laptop is powered by the Intel Core Ultra 7 258V flagship processor from the Series 2 "Lunar Lake" family . It features 8 cores (4 Performance cores and 4 Low Power Efficient cores) and 8 threads, with P-cores boosting up to 4.8 GHz and a 12MB Intel Smart Cache . This processor is designed for exceptional performance-per-watt computing .

The processor integrates Intel AI Boost with up to 47 TOPS of NPU performance, delivering accelerated AI-enhanced workflows and intelligent performance optimization . As a Copilot+ PC, the ThinkPad X9-14 integrates advanced AI capabilities to improve task management through real-time suggestions, automation of routine processes, and personalized insights . The processor also features Intel Evo Platform certification for premium mobile performance .

The integrated Intel Arc Graphics 140V delivers exceptional graphics performance for content creation, multimedia, and demanding business applications .

Fast LPDDR5X Memory & PCIe Gen4 Storage

The system is equipped with 32GB of soldered LPDDR5X-8533 Memory on Package (MoP) memory, providing exceptional bandwidth for smooth multitasking and application responsiveness . The memory is soldered to the system board and is not upgradable .

The 1TB PCIe 4.0x4 NVMe SSD with Opal 2.0 encryption delivers rapid boot times, quick application loading, and fast file access . The storage supports up to a 2TB M.2 2242 SSD upgrade .

Comprehensive Connectivity & Port Selection

The ThinkPad X9-14 offers a carefully curated selection of ports for business professionals:

• 2x Thunderbolt 4 / USB4 40Gbps (USB PD 3.0, DisplayPort 2.1)

• 1x HDMI 2.1 (Supports up to 4K/60Hz)

• 1x Headphone / microphone combo jack (3.5mm)

The laptop features Intel Wi-Fi 7 (BE201 2x2) and Bluetooth 5.4 for next-generation wireless connectivity . There is no wired Ethernet port, supporting the ultraportable design .

Premium Features & Enterprise-Grade Security

The ThinkPad X9-14 features a re-engineered backlit keyboard with tighter key travel and precise tactile feedback, elevating the typing experience . The haptic touchpad provides responsive, buttonless glass surface navigation .

Security features include an 8MP RGB+IR camera with E-Shutter physical privacy shutter, a match-on-chip fingerprint reader integrated into the power button, Human Presence Detection (HPD), and discrete TPM 2.0 . Windows Hello facial recognition enables secure, convenient login .

Long-Lasting Battery & Fast Charging

The 55Wh battery with Rapid Charge technology delivers up to 80% charge in just one hour with the included 65W USB-C Slim GaN adapter . The system includes a 3-year carry-in warranty, providing long-term reliability for enterprise deployments .

---

Core Features

• The 14-inch 2.8K OLED anti-reflection touch display with 500 nits brightness and 120Hz VRR delivers stunning visuals and responsive interaction.

• The flagship Intel Core Ultra 7 258V processor with Intel AI Boost (47 TOPS) accelerates AI-powered business computing and creative workflows.

• 32GB LPDDR5X-8533 MoP memory guarantees exceptional application response times and fluid multitasking.

• High-speed 1TB PCIe Gen4 NVMe SSD with Opal 2.0 encryption enables rapid boot times and quick file access.

• The 8MP RGB+IR Hybrid webcam with E-Shutter privacy shutter and match-on-chip fingerprint reader delivers comprehensive biometric authentication and visual security.

• Thunderbolt 4 connectivity enables 40Gbps data transfers and multi-display capabilities.

• Wi-Fi 7 and Bluetooth 5.4 provide next-generation wireless connectivity for maximum mobility.

---

Performance & Utility Features

• The Intel Core Ultra 7 258V utilizes advanced Lunar Lake architecture and integrated AI Boost (47 TOPS) for optimal power efficiency and computing speed .

• Intel Arc Graphics 140V delivers exceptional visual performance for content creation and multimedia .

• Intel Evo Platform certification ensures premium mobile performance and responsiveness .

• AI-powered Copilot+ features enhance productivity with real-time suggestions and task automation .

• Stereo speakers (2W x2) with Dolby Atmos deliver immersive audio for entertainment and video conferencing .

---

Design, Build & Sustainability

• The ThinkPad X9-14 chassis meets MIL-STD-810H military-grade durability standards for reliability in extreme conditions .

• The re-engineered backlit keyboard ensures comfortable typing with improved tactile feedback.

• The physical webcam privacy shutter grants immediate visual security protection.

• The laptop features an aluminum top and bottom cover, offering a premium feel and durability .

• Constructed with sustainable materials including recycled aluminum and post-consumer recycled plastics.

• ENERGY STAR 8.0 certified, EPEAT Gold registered, and TCO 10.0 certified for environmental sustainability .

• The 3-year carry-in warranty provides long-term reliability for enterprise deployments.

---

Technical Specifications Summary

• Model / Part Number: Lenovo ThinkPad X9-14 Aura Edition (21QA0014UE)

• Processor: Intel Core Ultra 7 258V (8 Cores: 4P + 4LPE, Up to 4.8 GHz Max Boost, 12MB Cache) with Intel AI Boost (up to 47 TOPS)

• AI PC Category: Copilot+ PC

• Graphics: Integrated Intel Arc Graphics 140V

• Chipset: Intel SoC Platform

• Memory: 32 GB Soldered LPDDR5X-8533 MoP Memory (Not Upgradable)

• Storage: 1 TB SSD M.2 2242 PCIe 4.0x4 NVMe Opal 2.0

• Display: 14-inch 2.8K (2880 x 1800) OLED Touch, Anti-Reflection/Anti-Smudge, 500 nits, 100% DCI-P3, 30-120Hz VRR, DisplayHDR True Black 600, Dolby Vision

• Operating System: Windows 11 Pro

• Optical Drive: None

• Camera: 8MP RGB+IR Hybrid with E-Shutter Privacy Shutter, ToF Sensor, Human Presence Detection

• Wireless Connectivity: Intel Wi-Fi 7 (BE201 2x2) and Bluetooth 5.4

• Ethernet: No Wired Ethernet

• Security Features: Match-on-Chip Touch Fingerprint Reader (Y-FPR), IR Facial Recognition, Web Camera Privacy Shutter, Discrete TPM 2.0, Human Presence Detection

• Keyboard: UK English Backlit Keyboard with Haptic Touchpad

• Battery Type: 3-Cell 55Wh Battery with Rapid Charge

• Power Supply: 65W USB-C Slim GaN Power Adapter (3PIN-UK)

• Dimensions (WxDxH): 311.8 x 212.3 x 6.7-17.18 mm

• Weight: Starting at 1.21 kg

• Color: Thunder Grey (Aluminum Top & Bottom)

• Warranty: 3 Year Carry-in Warranty
