HPE 1.2TB SAS 12G SAS 10K SFF BC MV HDD

Technical Specifications

• Capacity: 1.2TB
• Form Factor: 2.5-inch Small Form Factor (SFF)
• Interface: SAS (Serial Attached SCSI) 12Gbps
• Rotational Speed: 10,000 RPM
• Cache Buffer: 256MB (Typical for this class of HDDs)
• Average Latency: 2.9ms
• Sector Format: 512e (Advanced Format)
• Data Transfer Rate: Up to 1.2GB/s (SAS 12Gbps)
• MTBF (Mean Time Between Failures): 2.5 million hours
• Annualized Failure Rate (AFR): 0.35%

Physical & Environmental

• Drive Dimensions: 2.5" (SFF) drive
• Hot-Swap Support: Yes (Hot-pluggable with Smart Carrier)
• Power Consumption:
  • Idle: ~4.2W
  • Active (Read/Write): ~8-9W
• Operating Temperature: 5°C to 55°C (41°F to 131°F)
• Weight: ~0.5 kg (~1.1 lbs)

Key Features

✔ Enterprise-Class Reliability – Designed for 24/7 operation in data centers
✔ Multi-Vendor Compatibility – Works with various HPE ProLiant Gen9, Gen10, and Gen11 servers
✔ Advanced Error Correction – Ensures data integrity with SAS technology
✔ Hot-Pluggable – Can be replaced without system shutdown

• Data Sheet
