DH-PFA150 Pole Mount Bracket

Physical Specifications

• Material: Built of SECC and SUS304 stainless steel for durability .
• Dimensions: 130.4 mm × 170.0 mm × 45.0 mm (W × H × D) .
• Weight: Approximately 1.1 kg (2.43 lb) net weight .
• Color: Available in White (standard), Black (DH-PFA150-B), and Silver Gray (DH-PFA150-SG) .

Protection & Environment

• Operating Temperature: -40°C to +60°C (-40°F to +140°F) .
• Operating Humidity: <90% RH .
• Load Bearing: Supports a maximum weight of 10.0 kg (22.05 lb) .

Design & Installation

• Pole Compatibility: Designed for poles with a diameter of Φ80 mm to 150 mm (Φ3.15" to 5.91") .
• Compatibility: Can be combined with junction boxes, wall mount brackets, power boxes, universal joints, and more .
