D-Link 28-Port Gigabit Smart Managed PoE Switch (DGS-1210-28P)

Here's a detailed overview of the D-Link DGS-1210-28P 28-Port Gigabit Smart Managed PoE Switch:

---

📘 D-Link DGS-1210-28P – 28-Port Gigabit Smart Managed PoE Switch

🔌 Hardware Overview

• Ports:
  • 24 × 10/100/1000BASE-T PoE ports
  • 4 × Gigabit RJ45/SFP Combo ports
• Switching Capacity: 56 Gbps
• Forwarding Rate: 41.7 Mpps
• MAC Address Table: 8K entries
• PoE Standards: IEEE 802.3af/at
• PoE Budget: Up to 193W total
  • Ports 1–4: Up to 30W per port
  • Ports 5–24: Up to 15.4W per port
• Energy Efficiency: IEEE 802.3az Energy Efficient Ethernet (EEE) compliant

⚙️ Software & Management Features

• Management Interfaces:
  • Web-based GUI
  • Command Line Interface (CLI) via Telnet/SSH
  • SNMP v1/v2c/v3
• VLAN Support:
  • 802.1Q VLAN
  • MAC VLAN
  • Voice VLAN
  • Auto Surveillance VLAN
  • Supports up to 256 VLANs
• Quality of Service (QoS):
  • 8 queues per port
  • 802.1p CoS, DSCP, SP, WRR scheduling
• Security Features:
  • Access Control Lists (ACLs)
  • Port Security
  • 802.1X Authentication
  • IP-MAC-Port Binding
  • DoS Protection
  • DHCP Snooping
  • SSL, SSH, HTTPS support
• Layer 2 Features:
  • Spanning Tree Protocol (STP), Rapid STP (RSTP), Multiple STP (MSTP)
  • Link Aggregation (Static and LACP)
  • IGMP Snooping v1/v2/v3
  • Loopback Detection
  • Port Mirroring
  • Storm Control (Broadcast/Multicast/Unknown Unicast)
• IPv6 Support:
  • IPv6 Ping, Traceroute, Telnet, SSH
  • IPv6 SNMP, LLDP
  • IPv6 DHCP Client

🌿 Energy Efficiency

• Energy-Efficient Ethernet (EEE): Compliant with IEEE 802.3az
• Power Saving Features:
  • Link status detection
  • LED shut-off
  • Port shut-off
  • System hibernation
• Time-Based PoE: Schedule PoE power delivery

📏 Physical & Environmental Specifications

• Dimensions: 440 × 250 × 44 mm
• Weight: 3.7 kg
• Operating Temperature: -5°C to 50°C
• Storage Temperature: -20°C to 70°C
• Operating Humidity: 0% to 95% RH (non-condensing)
• Storage Humidity: 0% to 95% RH
• Power Input: 100-240 VAC, 50-60 Hz
• Maximum Power Consumption:
  • PoE enabled: 263.9 W
  • PoE disabled: 30.6 W
• Standby Power Consumption:
  • 19.6 W (100V)
  • 16.6 W (240V)
• Heat Dissipation:
  • 900.36 BTU/hr (100V)
  • 844.23 BTU/hr (240V)
• Fan Quantity: 2
• Acoustics:
  • High speed: 51.7 dB(A)
  • Low speed: 44.9 dB(A)
• MTBF: 469,262 hours

📦 Package Contents

• DGS-1210-28P Switch
• Power Cord
• Rack Mount Kit
• User Manual

---
