Bixolon XD5-40T Label Printer

The Bixolon XD5-40t is a 4-inch thermal transfer desktop label printer designed for mid-tier industrial applications such as logistics, manufacturing, healthcare, and retail. It offers robust performance, versatile media handling, and multiple connectivity options.

---

🔑 Key Features

• Print Method: Thermal Transfer
• Print Speed: Up to 6 inches per second (152 mm/sec)
• Resolution: 203 dpi (optional 300 dpi)
• Print Width: Up to 108 mm
• Media Width: 15 to 118 mm
• Media Roll Diameter: Up to 127 mm
• Ribbon Support: Supports 74 m and 300 m ribbons with 0.5-inch and 1-inch cores
• Interfaces:
  • Standard: USB 2.0, USB Host
  • Optional: Serial, Ethernet, Dual-band WLAN (5 GHz and 2.4 GHz), Bluetooth V5.0 (MFi certified)
• Memory: Up to 256 MB SDRAM, 256 MB Flash
• Sensors: Transmissive (Fixed), Reflective (Adjustable), Head Open
• Dimensions (W x D x H): 210 x 284 x 188 mm
• Weight: 2.48 kg
• Energy Certification: EnergyStar Certified

---

🧩 Design & Usability

• User-Friendly Design: Compact clamshell design with intuitive menu buttons and optional LCD display
• Media Handling: Adjustable media guide and holder for various media types
• Optional Accessories: Field-installable Peeler, Auto Cutter, External Paper Supply
• Smart Media Detection™: Automatic detection of Gap, Black Mark, Continuous, or Notch media formats
• Twin Function™: Copy printer settings and data via USB for efficient deployment

---

🔌 Connectivity & Compatibility

• Interfaces:
  • Standard: USB 2.0, USB Host
  • Optional: Serial, Ethernet, Dual-band WLAN (5 GHz and 2.4 GHz), Bluetooth V5.0 (MFi certified)
• Programming Languages: Supports SLCS™, BPL-Z™, BPL-E™
• Software Compatibility: Compatible with BIXOLON’s Label Artist™ and Seagull's BarTender®
• Management Tools: XPM™ & XCM™ - Web-based printer management software and connection app

---
