Bixolon XD5-40d Label Printer

The Bixolon XD5-40d is a 4-inch (118 mm) direct thermal desktop label printer designed for high-performance and cost-effective printing in various industries, including retail, logistics, manufacturing, and healthcare.

---

🖨️ Key Features

• Print Method: Direct Thermal

• Print Speed: Up to 7 inches per second (178 mm/sec)

• Print Resolution: 203 dpi (optional 300 dpi)

• Print Width: Up to 108 mm

• Media Width: 15 to 118 mm

• Media Roll Diameter: Up to 127 mm

• Media Types: Gap, Black Mark, Notch, Continuous, Fan-Fold

• Sensors: Transmissive (Fixed), Reflective (Adjustable), Head Open

• Interfaces:

  • Standard: USB 2.0, USB Host

  • Optional: Serial, Ethernet, Dual-band WLAN (5 GHz and 2.4 GHz), Bluetooth V5.0 (MFi certified)

• Memory: Up to 256 MB SDRAM, 512 MB Flash

• Dimensions (W x D x H): 194 x 248 x 169 mm (7.64 x 9.76 x 6.65 inches)

• Weight: 1.89 kg (4.17 lbs.)

• Energy Certification: EnergyStar Certified

---

🧩 Design & Usability

• User-Friendly Design: Compact clamshell design with intuitive menu buttons and optional LCD display

• Media Handling: Adjustable media guide and holder for various media types

• Optional Accessories: Field-installable Peeler, Auto Cutter, External Paper Supply

• Smart Media Detection: Automatic detection of Gap, Black Mark, Continuous, or Notch media formats

• Twin Function™: Copy printer settings and data via USB for efficient deployment

---

🔌 Connectivity & Compatibility

• Interfaces:

  • Standard: USB 2.0, USB Host

  • Optional: Serial, Ethernet, Dual-band WLAN (5 GHz and 2.4 GHz), Bluetooth V5.0 (MFi certified)

• Programming Languages: Supports SLCS™, BPL-Z™, BPL-E™

• Software Compatibility: Compatible with BIXOLON’s Label Artist™ and Seagull's BarTender®

• Management Tools: XPM™ & XCM™ - Web-based printer management software and connection app

---

For more detailed information, including driver downloads and manuals, you can visit the official Bixolon XD5-40d support page: Datasheet
